Drive-in-a-Box

Waypoint's Fully-Loaded Turn-key Automation Solution

• Perfect for adding automation & functionality to production lines
• Control I/O, Remote Access, and Plant Floor Visualization - all in one
• Supports EtherNet/IP for easy integration with Allen Bradley systems
• Comes pre-wired & ready for integration

Specs:

Horner OCS X7 — All-in-one PLC & HMI

• 7" Color Touchscreen
• 12 Digital Inputs - 24VDC – can be usd for four 10kHz High Speed Counters
• 6 Relay Outputs (3A)
• 2 DC sinking outputs – 0.5A per point that can be used as PWM/pulse outputs.
• 4 Analog Inputs 4-20mA or up to 4 RTD Inputs
• 2 Analog Outputs 4-20mA
• Ethernet & Serial communications, including EtherNet/IP & Modbus
• Free Software & WebMI remote access


Secomea SiteManager - IoT Gateway

• Secure remote access to factory machinery & process data- from anywhere in the world
• Integrated LAN & Wifi, with cellular options available

Maple Systems cMT — Plant Floor Visualization

• HDMI port allows any size TV to become productivity display for Overall Equipment Effectiveness, trends, and general process data
• Highly-customizable via free programming software

Power, Protection, and Installation

• 18 x 16 x 10 inch Non-Metallic 4X Enclosure

• Power Supply with 100-240VAC Input and 24VDC Output, 4.2A

• UL489 Miniature Circuit Breaker and Type 3 Surge Protection Device
• Cable Entry System with 16 Positions (3.5mm-16.5mm diameter each)

Pilot Devices

• Programmable indicator light with wide variety of colors & flash patterns
• Key-latch On/Off switch
